AMD RX 7800 XT vs Nvidia RTX 4070 vs 4070 Ti comparison – a potential Nvidia killer?

We’re bringing you our comparison between RX 7800 XT vs RTX 4070 vs 4070 Ti to help you pick your next graphics card.

With the release of the RX 7800 XT, it’s time to take a closer look at AMD’s latest entry to the RX 70-series cards that serves as a successor to the infamous RX 6800 XT. Expected to deliver excellent performance at both 1440p and 4K, the early rumoured leaks are suggesting the RX 7800 XT is here to excel as a midrange graphics card. Make sure you know where to buy the RX 7800 XT if you’re planning on getting it.

The RTX 4070 was released in April 2023, and its Ti variant was released in January 2023. The RTX 4070 is intended for 1440p gaming, whereas the RTX 4070 Ti can easily handle 4K without any hiccups. Both cards benefit significantly from Nvidia’s DLSS 3.0 and Ray Tracing technologies, though some have felt disappointed by Nvidia’s chosen MSRP. Still ,we’ve seen these cards reduced, so make sure to get the best RTX 4070 and the best RTX 4070 Ti graphics cards.

Should you go with Team Green, or is the latest card from Team Red superior?

RX 7800 XT vs RTX 4070 vs 4070 Ti – architecture

It is very important to compare the architecture first because it shows which card has more performance, better efficiency, and extra features.

The RX 7800 XT is based on RDNA 3, which is AMD’s latest architecture. AMD went all in with RDNA 3 as they brought several massive improvements intended for both performance and efficiency. For instance, RDNA 3 is the world’s first architecture to use a chiplet design for GPUs. It is also the first time AMD has moved to TSMC’s 5nm process node. These improvements turned out to be very beneficial for AMD because they made the RX 70 series up to 50% more power efficient. To get a more detailed breakdown, take a look at the comparison between the RDNA 2 and the RDNA 3. AMD also introduced AI Acceleration, 2nd gen Raytracing, and 2nd gen Infinity Cache with RDNA 3 for better performance at upscaled resolutions.

The RTX 4070 and the RTX 4070 Ti are built on the Ada Lovelace architecture. Nvidia also shifted to TSMC’s 5nm with Ada Lovelace because they were previously using Samsung’s 8nm process node. Along with efficiency improvements, Ada Lovelace cards also utilize 4th gen Tensor Cores along with 3rd gen RT cores for better DLSS and Ray Tracing performance.

Overall, both architectures are quite solid because they are the latest from their respective manufacturers. However, the use of dedicated Tensor cores for DLSS gives the RTX 4070 and Ti an edge in upscaled gaming.

FSR 3.0 vs DLSS 3.0?

FSR 3.0 is AMD’s latest upscaling technology that brings together the traditional FSR with Fluid Motion Frames. In simple words, FSR 3.0 can now deal with both upscaled resolution and frame generation for extra performance, a feat that was only achieved by DLSS 3 before.

Another good thing about FSR 3.0 is that it is software-based, meaning it can work with all Radeon RX 5700 and above cards, including the RX 60 and RX 70 series. Furthermore, FSR 3.0 is also compatible with RTX 30 and 40 series graphics cards.

Nvidia also just announced DLSS 3.5, which can work with all RTX graphics cards. DLSS 3.5 uses AI to increase Ray Tracing performance. This way, the RTX cards, which were already known for their exceptional RT performance, can get an even better boost. It should be noted here that DLSS 3.5 does not bring frame generation to RTX 20 and 30 series cards. It only uses the traditional DLSS and merges it with a Ray Reconstruction element.

RX 7800 XT vs RTX 4070 vs 4070 Ti – specs comparison

Specs	RX 7800 XT	RTX 4070	RTX 4070 Ti
GPU Architecture	RDNA 3.0	Ada Lovelace	Ada Lovelace
Cores	3840	5888	7680
Base clock	1800 MHz	1920 MHz	2310 MHz
Boost clock	2430 MHz	2480 MHz	2610 Mhz
Die Size	346 mm²	294 mm²	294 mm²
Memory	16 GB GDDR6	12 GB GDDR6X	12 GB GDDR6X
Bandwidth	624 GB/s	504.2 GB/s	504.2 GB/s
TGP	263 W	200 W	285 W

It is evident by the specifications that the RTX 4070 and the RTX 4070 Ti have overall better numbers than the RX 7800 XT. However, the RX 7800 XT really shines in the VRAM department because it has 4 GB extra memory with higher bandwidth. This gives the RX 7800 XT a solid advantage in gaming benchmarks because VRAM matters a lot.

As for the rest, both the RTX 4070 and Ti have higher cores and higher clock speeds than the RX 7800 XT. It should be noted that the RTX 4070 is the most power-efficient of the bunch, and the RTX 4070 Ti is the least efficient. If you are considering these cards then make sure you’ve got the best PSU for the RTX 4070 or the best for the RTX 4070 Ti.

Overall, the RTX 4070 Ti has better numbers. Yes, the RX 7800 XT has 4 GB more VRAM, but the RTX 4070 Ti has literally twice as many cores as the RX 7800 XT, along with higher clock speeds.

RX 7800 XT vs 4070 vs 4070 Ti – performance

When it comes to performance, the RX 7800 XT will face no trouble handling both 1440p and 4K games. It has 16 GB of VRAM, which gives it a huge advantage over the competition.

On the other hand, the RTX 4070, on average, should give you around 60 FPS at 4K, 100 FPS at 1440p, and 150 FPS at 1080p. Thanks to its extra cores and clock speeds, the RTX 4070 Ti takes things one step further, with an average of 90 FPS at 4K, 150 FPS at 1440p, and 200 FPS at 1080p. To get a more detailed breakdown, take a look at the comparison between the RTX 4070 and RTX 4070 Ti.

This means that the RX 7800 XT can come close to the RTX 4070 in rasterization, but it will have trouble reaching the level of the RTX 4070 Ti. Plus, if we shift towards DLSS or Ray Tracing, then it’s a clear win for Nvidia.

RX 7800 XT vs RTX 4070 vs 4070 Ti – price comparison

In terms of pricing, AMD has listed the RX 7800 XT at $500. This is a really impressive price tag because the RX 7800 XT offers excellent performance. If you go for its high-end variant, that will set you back by around $530 to $540.

Right now, the RTX 4070 falls anywhere between $590 to $700 or more. Similarly, the RTX 4070 Ti can range from $780 to $850. These are undoubtedly expensive graphics cards, but their performance makes up for it.

If you’re searching for the best pocket-friendly option, then you should consider the RX 7800 XT. It is the cheapest of the three.

RX 7800 XT vs RTX 4070 vs 4070 Ti – final word

All in all, if you’re looking for the best performance possible, then you should go for the RTX 4070 Ti. The card can easily handle 4K gaming and will last you for several years to come. However, if you want a mid-range option that still offers excellent performance, then the RX 7800 XT is perfect for the job. Similarly, if you want somewhat the best of both worlds, then the RTX 4070 is a good deal, especially if you turn on DLSS.
