We’re bringing you our RX 7700 XT vs RX 6800 XT comparison to help you pick your next gaming graphics card.
With the release of the RX 7700 XT, it’s time to take a look at AMD’s latest RX 7000-series card that is meant to handle 1440p gaming while maintaining a tempting price-to-performance ratio. AMD also released its latest FSR and Hyper-RX features along with this card. If you plan to get it, then make sure you know where to buy the RX 7700 XT.
The RX 6800 XT was released back in late 2020. It was AMD’s mid-range solution for 1440p and 4K gaming. The card quickly gained popularity because of its excellent performance and affordable pricing. For the ideal experience, make sure you get the best RX 6800 XT graphics card.
RX 7700 XT vs RX 6800 XT – architecture
When it comes to comparing two graphics cards, it’s important to compare their architectures as well because it shows which graphics card can pack more performance, stay more power efficient, and support extra features.
The RX 7700 XT is built on the RDNA 3 architecture. AMD has brought several key improvements to RDNA 3, including shifting to TSMC’s 5nm process node from 7nm. Apart from that, AMD also made the world’s first GPU chiplet with RDNA 3, which has given the RX 7000-series cards up to 50% more power efficiency than their RX 6000-series counterparts. For better performance, RDNA 3 also packs 2nd gen Raytracing, 2nd Infinity Cache, and AI acceleration to boost performance with frame generation and upscaled resolution.
The RX 6800 XT is based on the RDNA 2 architecture. When it comes to RDNA 3 vs RDNA 2, RDNA 3 is a clear winner. RDNA 2 cards are built using TSMC’s 7nm process node, which is not as efficient as RDNA 3. AMD brought 1st gen Raytracing and 1st gen Infinity Cache with RDNA 2, but these cards don’t have AI Accelerations.
Overall, the RX 7700 XT wins in terms of architecture. The card is more future-proof, more efficient, and packs more performance with its 5nm process node.
RX 7700 XT vs RX 6800 XT – specs difference
| Specs | RX 7700 XT | RX 6800 XT |
| GPU Architecture | RDNA 3.0 | RDNA 2.0 |
| Cores | 3456 | 4608 |
| Base clock | 1900 MHz | 1825 MHz |
| Boost clock | 2544 MHz | 2250 MHz |
| Die Size | 346 mm² | 520 mm² |
| Memory | 12 GB GDDR6 | 16 GB GDDR6 |
| Bandwidth | 432 GB/s | 512 GB/s |
| TGP | 245 W | 300 W |
Going over the specifications, the RX 6800 XT is winning across the board, with the RX 7700 XT only succeeding with higher base and boost clock speeds. Apart from that, the RX 6800 XT offers 1152 more cores and 4GB extra VRAM with boosted bandwidth. Of course, this also means that the RX 6800 XT will be consuming more power, and that’s evident by its 55W higher TGP.
It makes sense that the RX 7700 XT cannot surpass the RX 6800 XT because it is meant to be an upgrade over the RX 6700 XT. Nevertheless, if you want higher numbers on paper, then you should go with the RX 6800 XT.
RX 7700 XT vs RX 6800 XT – performance
You cannot pick between two graphics cards without going through their performance. The RX 7700 XT will sit below the RTX 4070 and above the RX 6800. As for gaming, the card has no issues running at 1440p and even playable FPS at 4K.
As for the RX 6800 XT, the card has a Time Spy score of around 19500, which puts it around 14% above the RX 7800 XT. Since the RX 6800 XT has been available for quite some time, we also have access to its gaming benchmarks. On average, you should expect around 180 FPS at 1080p, 150 FPS at 1440p, and 80 FPS at 4K. These are very good numbers, and they definitely give an edge to the RX 6800 XT.
RX 7700 XT vs RX 6800 XT – price difference
Going over the price, the RX 7700 XT is listed for $450. Since it’s a new card, we don’t expect its prices to fall down anytime soon. You can find its high-end variants reaching $470 to $480.
Where to buy the RX 7700 XT:
- Gigabyte Radeon RX 7700 XT Gaming OC 12GB GDDR6 Graphics Card
- XFX Speedster QICK319 AMD Radeon RX 7700 XT Black 12GB GDDR6 Graphics Card
- ASRock Challenger Radeon RX 7700 XT
- PowerColor RED DEVIL Radeon RX 7700 XT
- SAPPHIRE NITRO+ Radeon RX 7700 XT
On the other hand, the RX 6800 XT was launched for $650. However, you can get one for around $500 right now. Not only that, but now the RX 7700 XT is released, the previous-gen RX cards will drop in price, and that includes the RX 6800 XT. This drop will further make the RX 6800 XT a better value-for-money deal.
ASUS ROG Strix RX 6800 XT
Base Clock
1925 MHz
Boost Clock
2360 MHz
VRAM
16GB GDDR6
Recommended PSU
700W
Dimensions
267 x 120 x 50 mm
RX 7700 XT vs RX 6800 XT – final word
All things considered, the only reason to go for the RX 7700 XT over the RX 6800 XT is if you want the latest graphics card with improved architecture. Apart from that, the RX 6800 XT is the better overall deal. It has more performance, and its pricing makes it the better bang for the buck.
